Distribution Tight Buffer Fiber Cable

Universal (Indoor/Outdoor) tight buffered with Steel Wire Armouring optical fiber cable with glass yarns as strength member and improved rodent protection with Low Smoke Zero Halogen outer jacket. 8 fibers SM OS2 G.652.D & G.657.A1. CPR Euroclass Eca.

上架时间:

Global
状态:

有源

报价

规格
零件编号
资源

规格

Expand All

Product Overview

Suitable Applications	For outdoor and indoor use in structured (data) wiring systems such as industrial backbone, campus backbone, building backbone (riser) and/or horizontal cabling. For outdoor and indoor use in networks for industrial, telecom, cable TV and/or broadcast. Support all computer network applications such as FDDI, Gigabit Ethernet and ATM.

Fiber Specifications

Fiber Type	OS2
Fiber Grade Acc to ITU-T	G.652D & G.657A1
Fiber Buffer Material	LSZH - Low Smoke Zero Halogen (Flame Retardant)
Fiber Buffer Construction	Tight
Fiber Buffer Diameter	0.9 mm
Fiber Count	8
Fiber Color Coding	TIA coding (Gxxxxxx.T): Blue, Orange, Green, Brown, Gray, White, Red, Black

Cable Construction

Cable Core Water Blocking	Waterblocking Glass Yarns

Inner Jacket Specifications

Material	LSZH - Low Smoke Zero Halogen (Flame Retardant)

Armor Specifications

Armor Type and Material	SWA - Steel Wire Armor

Outer Jacket Specifications

Jacket Material	LSZH - Low Smoke Zero Halogen (Flame Retardant)
Nom. Diameter	11.1 mm (0.437 in)

Optical Characteristics

Wavelength	1310 nm	1550 nm	1625 nm
Max. Attenuation	0.40 dB/km	0.30 dB/km	0.30 dB/km

Mechanical Characteristics

Mechanical Tests

Description	Tested Standard	Requirement/Value	According to Family Specification
Cable Min. Bend Radius Installation (Short Term)	IEC 60794-1-21-E6	222 mm	IEC 60794-2-20
Cable Min. Bend Radius Operation (Long Term)	IEC 60794-1-21-E11	166.5 mm	IEC 60794-2-20
Cable Max. Tensile Strength Installation (Short Term)	IEC 60794-1-21-E1	2520 N (567 lbf)	IEC 60794-2-20
Cable Max. Tensile Strength Operation (Long Term)	IEC 60794-1-21-E1	840 N (190 lbf)
Cable Max. Crush Resistance Installation (Short Term)	IEC 60794-1-21-E3	22 kN/m	IEC 60794-2-20
Cable Max. Crush Resistance Operation (Long Term)	IEC 60794-1-21-E3	11 kN/m	IEC 60794-2-20

Bulk Cable Weight	251 kg/km (169 lbs/1000ft)

Temperature Range

Installation Temperature Range	-5 °C to +50 °C
Operating Temperature Range	-30 °C to +70 °C
Storage Temperature Range	-30 °C to +70 °C

Standards and Compliance

Environmental Suitability	Indoor/Outdoor - Euroclass Eca
Flammability / Reaction to Fire	IEC 60332-1-2, IEC 60332-3-22
CPR Compliance	CPR Euroclass: Eca
ISO/IEC Compliance	IEC 60794ISO/IEC 11801-1
European Halogen Free Standards	IEC 60754-1 - Halogen Amount = Zero, IEC 60754-2 - Halogen Acid Gas Amount - Max. Conductivity = 10 µS/mm, IEC 60754-2 - Halogen Acid Gas Amount - Min. pH = 4.3
UK Regulation Compliance	UKCA Mark
